Figure 29: 20-Port 10-Gigabit Ethernet Modular Port Adapter with SFP+
LED status could be wrong when a port is put into loopback internal mode on Gigabit Ethernet interface for
20x1EP. Loopback internal is used for debugging purpose.
Note
1-Port 40-Gigabit Ethernet Modular Port Adapter with QSFP+
The 1-Port 40-Gigabit Ethernet (GE) modular port adapter (MPA) provides a cage for a QSFP+ Ethernet
optical interface module that operates at a rate of 40 Gbps. The QSFP+ module can support either a 40GE
multimode connection or a 40GE single mode connection.
Each QSFP cage on the 1-Port 40GE MPA has an adjacent A/L (Active/Link) LED visible on the front panel.
The A/L LED indicates the status of the associated QSFP port, as described in 1-Port 40-Gigabit Ethernet
MPA LEDs table below and a Status LED as shown in the following figure.
Cisco ASR 9000 Series Aggregation Services Router Ethernet Line Card Installation Guide
60
Overview
1-Port 40-Gigabit Ethernet Modular Port Adapter with QSFP+
