Specifications
D - 2 Specifications
D
Note
Core Logic
Intel® Z270 Express Chipset
Display
For All Systems:
17.3" (43.94cm) UHD (3840 * 2160), FHD
(1920 * 1080), 4.0mm, 16:9 Backlit Panel
===============================
*
For Systems with NVIDIA® G-SYNC™
Technology Only:
17.3" (43.94cm) UHD (3840 * 2160),
QHD (2560 * 1440), FHD (1920 * 1080),
4.0mm, 16:9 Backlit Panel
CPU Speed & Computer in DC Mode
Note that when the computer is in DC
mode (powered by the battery only) the
CPU may not run at full speed. This is a
design feature implemented in order to
protect the battery.
Memory
Dual Channel DDR4
Four 260 Pin SO-DIMM Sockets
Supporting DDR4 2400 MHz Memory
Modules (real operational frequency
depends on FSB of processor)
Memory Expandable from 8GB
(minimum) to 64GB (maximum)
Compatible with 4GB/8GB/16GB Modules
Supports XMP 2666/3000 MHz
(XMP support depends on processor and
works with
four
DIMMs)
SO-DIMM Memory Types
All SO-DIMM memory modules installed in the
system should be identical (the same size and
brand) in order to prevent unexpected system
behavior.
Do not mix SO-DIMM memory module sizes
and brands otherwise unexpected system
problems may occur.
Storage
Two Changeable 2.5" 7mm/9.5mm (h)
Hard Disk Drives (HDD) / Solid State
Drives (SSD) with SATA Interface (RAID
0/1)
Two M.2 2280 SSDs with SATA Interface
(RAID 0/1) (Factory Option)
OR
Three M.2 2280 SSDs with PCIe Gen3 x4
Interface (RAID 0/1) (Factory Option)
Audio
High Definition Audio
One 2-In-1 Audio Jack - (Headphone /S/
PDIF Optical Output)
Built-In Array Microphone
2 Built-In 2W Speakers
One Built-in Subwoofer Speaker
Sound Blaster® X-Fi® MB5
ESS™ SABRE HIFI DAC for High
Resolution Headphone Audio
External 7.1CH Audio Output Supported
by Microphone, Line-In, Line-Out & 2-In-1
Audio Jacks
