4‐41
Engine
Drive Axle Assembly
No.
Part Name
Qty
Remarks
Disassembling the Drive axle
Remove the parts in the order listed
1
Clutch dog
1
2
High wheel gear
1
3
Middle drive gear
1
4
Driven sprocket
1
For installation, reverse the order
5
Drive axle
1
listed
