Cub Cadet Challenger 550 User Manual

2-21
Specifications
CHASSIS TIGHTENING TORQUES
Part to be Tightened
Thread
Size
Torque
Nm
Torque
Ft Lbs
Rubber connecting bracket 1(or 2) and frame
10mm
60
44
Engine and Rubber connecting bracket 2 (front)
10mm
60
44
6mm
8
5.9
Engine and Rubber connecting bracket 1 (rear)
8mm
22
16
6mm
8
5.9
Rear upper arm and frame
10mm
60
44
Rear lower arm and frame
10mm
60
44
Rear knuckle and rear upper arm
10mm
60
44
Rear knuckle and rear lower arm
10mm
60
44
Rear shock absorber and frame
10mm
60
44
Rear shock absorber and rear lower arm
10mm
60
44
Rear Balancing pole and frame
8mm
22
16
ball head of Rear Balancing pole and Rear Balancing pole
10mm
60
44
ball head of Rear Balancing pole and rear lower arm
10mm
60
44
Differential gear case and frame
10mm
60
44
Differential gear case filler plug
14mm
120
88
Differential gear case drain plug
10mm
60
44
Universal joint yoke and drive pinion gear
14mm
120
88
Differential motor and differential gear case cover
8mm
22
16
Differential gear case cover and differential gear case
8mm
22
16
Rear driving axle gear case and frame
10mm
60
44
Rear driving axle gear case filler plug
20mm
23
17
Rear driving axle gear case drain plug
10mm
20
14
Ring gear bearing housing and final drive gear case
8mm
22
16
10mm
60
44
Ring gear stopper nut
8mm
22
06
Bearing retainer and final gear pinion gear bearing
housing
65mm 170 125
Coupling gear and final drive pinion gear
12mm
80
58
Front upper arm and frame
10mm
60
44
Front lower arm and frame
10mm
60
44
Front shock absorber and frame
10mm
60
44
Front shock absorber and front upper arm
10mm
60
44
Steering shaft assembly and steering Cross member
8mm
22
16
Steering assembly and steering Cross member
8mm
22
16
Steering assembly and frame
10mm
60
44
Steering shaft assembly and frame
8mm
22
16
Steering wheel and steering shaft assembly
12mm
90
66
Steering knuckle and front upper arm
12mm
45
33
