5‐20
Chassis
Inspecting the Rear Brake Disc
1. Inspect the disc
Look for galling or damage
2. Measure the rear brake disc
deflection
Brake disc maximum deflection
0.10 mm (0.004 in)
3. Measure the Brake disc thickness
(a).
Brake disc minimum thickness
4.5 mm (0.18 in)
