D-Link DSR-Series User Manual 41
Section 5 - Connect to the Internet
WAN3 (3G Internet)
Path: Network > Internet > WAN3 Settings
This router supports the use of 3G Internet access. Cellular 3G internet access is available on WAN3 via a 3G
USB modem for DSR-1000 and DSR-1000N. The cellular ISP that provides the 3G data plan will provide the
authentication requirements to establish a connection. The dial Number and APN are speciīæc to the cellular
carriers. Once the connection type settings are conīægured and saved, navigate to the WAN status page (Setup >
Internet Settings > WAN3 Status) and Enable the WAN3 link to establish the 3G connection.
Note: A 3G USB modem can be conī£gured as the third WAN in DSR-1000 and DSR- 1000N.
Field Description
Reconnect Mode
Some ISPs may require you to pay for usage time. Select On Demand if this is the case. This will have the
router connect to the Internet only when you initiate an Internet connection. Select Always On to have the
router stay connected to the Internet.
Maximum Idle Time Enter the idle time in minutes before the router disconnects from the Internet (On Demand only).
User Name Enter your 3G account user name.
Password Enter your 3G account password.
Dial-in Number Enter the phone number to access your Internet.
Authentication Protocol Select one of following protocols from the drop-down menu: None, PAP or CHAP.
APN Required Toggle to ON if your ISP requires APN to connect.
APN Enter the APN (Access Point Name) provided by the ISP.
DNS Server Source Select either Get Dynamically from ISP or Use These DNS Servers to manually enter DNS servers.
Primary DNS Server If you selected āUse These DNS Serversā, enter the primary DNS server IP address.
Secondary DNS Server If you selected āUse These DNS Serversā, enter the secondary DNS server IP address.
MTU Size Select to use the default MTU value (1500) or select Custom to enter your own value.
Custom MTU Enter a MTU value to optimize performance with your ISP.
