Configure ports Supported protocols
Digi CM User Guide 52
Inactivity timeout - In seconds, the time set for inactivity to trigger an action. Setting the timeout
to 0 (zero) means no timeout.
Enable/Disable port escape sequence - Allows the port escape sequence to function.
Port escape sequence - The key combination to initiate port escape.
Port break sequence - The sequence of characters that sends a break character to a device.
Use comment - Determines whether a port user is prompted to add a comment each time the
port is accessed.
Quick connect via - Determines method for connecting to a port when in console server mode.
Available with Telnet.
Web applet encoding - Supported languages for Java terminal.
5 Click Save & apply.
Supported protocols
In configuring a serial port, you have three protocol options. The three protocols available are:
RawTCP, SSH, and Telnet. Choose SSH as the protocol when logging in from an SSH client program
to access a port. Choose RawTCP when connecting directly to a TCP socket. Choose Telnet when
logging in from a Telnet client program and accessing the ports. Use the Host mode configuration
page in the web interface to select the correct protocol.
Serial port parameters
In attaching a serial device to the Digi CM unit’s serial port, the port parameters must match. The
serial ports by default are enabled, meaning you have full access to the port. To configure the port
parameters for the Digi CM unit, do the following:
1 Access the web interface.
2 Under the Serial Port heading, Click Configuration.
3 Choose All or an Individual port > Serial port parameters.
4 Fill in the serial port parameters. The following are the defaults: bps=9600, data bits=8,
parity=none, stop bits=1, flow control=none, and DTR behavior=High when open.
5 Click Save & apply.
