Emerson Aventics G3 Series User Manual

G3 Series EtherCAT
TM
Technical Manual
2-14
TDG3ECM1-5EN 07/2020
Subject to change without notice
www.asco.com/g3
2000 Series Z-Board™ and Ribbon Cable Example
If fourteen (14) single solenoid and one (1) double solenoid valves are connected directly to the communication
node via their Z-Boards
™
, and one (1) single solenoid and four (4) double solenoid valves are connected to the
communication node via the ribbon cable, the following would be the valve side bit map:
Output Word
0
1
Output Byte
0
1
2
3
Output Bit No.
00
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
Solenoid Coil
Output No.
1 2 3 4 5 6 7 8 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
n/a
