Emerson Aventics G3 Series User Manual

G3 Series EtherCAT
TM
Technical Manual
4-25
TDG3ECM1-5EN 07/2020
Subject to change without notice
www.asco.com/g3
Power Consumption
Power Connection
Pin No. Function Description
1
0 VDC Common
(Valves and Outputs)
0 VDC Voltage used to power outputs
(valve coils and discrete outputs) SW
2
0 VDC Common
(Node and Inputs)
0 VDC Voltage used to power
discrete inputs and node electronics UNSW
3
Earth Ground
Protective Earth
4
+24 VDC
(Node and Inputs)
Voltage used to power
discrete inputs and node electronics UNSW
5
+24 VDC
(Valves and Outputs)
Voltage used to power outputs
(valve coils and discrete outputs) SW
Power Rating
• For maximum supply current capability please refer to page 8-63.
• Loads should not draw more than 0.5 Amps of current from any one individual discrete output point (Contact
factory for higher current capability requirements).
Component Voltage Tolerance
+24VDC
(Valves and Outputs)
Pins 1 and 4
+24VDC
(Node and Inputs)
Pins 2 and 3
Current Power Current Power
Solenoid Valve Coil 501 (Each)
24 VDC
+10%/-15%
0.03 A
0.80 W
0 A
0 W
Solenoid Valve Coil 502 (Each)
24 VDC
+10%/-15%
0.05 A
1.30 W
0 A
0 W
Solenoid Valve Coil 503 (Each)
24 VDC
+10%/-15%
0.07 A
1.70 W
0 A
0 W
Solenoid Valve Coil 2002 (Each)
24 VDC
+10%/-15%
0.02 A
0.48 W
0 A
0 W
Solenoid Valve Coil 2005 (Each)
24 VDC
+10%/-15%
0.06 A
1.44 W
0 A
0 W
Solenoid Valve Coil 2012 (Each)
24 VDC
+10%/-15%
0.11 A
2.64 W
0 A
0 W
Solenoid Valve Coil 2035 (Each)
24 VDC
+10%/-15%
0.11 A
2.64 W
0 A
0 W
Solenoid Valve Coil ISO 5599/2- SPA
24 VDC
+10%/-15%
0.17 A
4.08 W
0 A
0 W
Valve Adapter (Driver) 2000 series
24 VDC
+/- 10%
0.03A
0.72 W
0.02 A
0.48 W
Valve Adapter (Driver) 500 series
24 VDC
+/- 10%
0.03A
0.72 W
0.02 A
0.48 W
501 Series 32+ valve driver board
24 VDC
+/- 10%
0.03A
0.72 W
0.05 A
1.20 W
502 Series 32+ valve driver board
24 VDC
+/- 10%
0.03A
0.72 W
0.05 A
1.20 W
503 Series 32+ valve driver board
24 VDC
+/- 10%
0.03A
0.72 W
0.05 A
1.20 W
Digital Module (M12 style)
24 VDC
+/- 10%
0.04 A
0.96 W
0.05 A*
1.20 W*
Digital Module (M8 Style)
24 VDC
+/- 10%
0 A
0W
0.19A
4.56 W
Analog Module
24 VDC
+/- 10%
0.01 A
0.24 W
0.08 A*
1.92 W*
Sub-Bus Hub
24 VDC
+/- 10%
0 A
0 W
0.06 A
1.44 W*
RTD Module
24 VDC
+/- 10%
0.01 A
0.24 W
0.06 A
1.44 W*
Communication Module (Node)
24 VDC
+/- 10%
0.04 A
0.9 W
0.10 A*
2.50 W*
Sub-Bus Valve Module
24 VDC
+/- 10%
0.01 A
0.24 W
0.03 A*
0.72 W*
580 Sub-Bus Valve Module
24 VDC
+/- 10%
.034 A
0.8 W
0.04 A*
0.9 W*
Auto Recovery Module (ARM)
24 VDC
+/- 10%
0 A
0 W
0.03 A
0.72 W
ARM-Clip Module
24 VDC
+/- 10%
0 A
0 W
0.03 A
0.72 W
*
Current depends on graphic display brightness setting. Max. value shown with high brightness.
Values decrease by approx. 5% for Medium and 11% for Low brightness settings.
NOTE!
• Total power consumption for each Discrete I/O point is
dependent on the specific current draw of input sensor
