Network and Sub-Network Error Codes
Error Code
Error
Error Description
Module No.
Main Network
1
Output power not present on communication module
Comm.
2
Node / Input power is below 19VDC
Comm.
4
Error associated with a sub-bus module (see sub-bus error)
Comm.
8
short circuit detected on the sub-bus
Comm.
Sub Network
22
1
Module did not respond
1
23
1
Module did not respond
2
24
1
Module did not respond
3
25
1
Module did not respond
4
26
1
Module did not respond
5
27
1
Module did not respond
6
28
1
Module did not respond
7
29
1
Module did not respond
8
2A
1
Module did not respond
9
2B
1
Module did not respond
10
2C
1
Module did not respond
11
2D
1
Module did not respond
12
2E
1
Module did not respond
13
2F
1
Module did not respond
14
30
1
Module did not respond
15
31
1
Module did not respond
16
42
2
Switched power is missing
1
43
2
Switched power is missing
2
44
2
Switched power is missing
3
45
2
Switched power is missing
4
46
2
Switched power is missing
5
47
2
Switched power is missing
6
48
2
Switched power is missing
7
49
2
Switched power is missing
8
4A
2
Switched power is missing
9
4B
2
Switched power is missing
10
4C
2
Switched power is missing
11
4D
2
Switched power is missing
12
4E
2
Switched power is missing
13
4F
2
Switched power is missing
14
50
2
Switched power is missing
15
51
2
Switched power is missing
16
62
3
Combination of errors 1 and 2
1
63
3
Combination of errors 1 and 2
2
64
3
Combination of errors 1 and 2
3
65
3
Combination of errors 1 and 2
4
66
3
Combination of errors 1 and 2
5
67
3
Combination of errors 1 and 2
6
68
3
Combination of errors 1 and 2
7
69
3
Combination of errors 1 and 2
8
6A
3
Combination of errors 1 and 2
9
6B
3
Combination of errors 1 and 2
10
6C
3
Combination of errors 1 and 2
11
6D
3
Combination of errors 1 and 2
12
6E
3
Combination of errors 1 and 2
13
6F
3
Combination of errors 1 and 2
14
70
3
Combination of errors 1 and 2
15
71
3
Combination of errors 1 and 2
16
