G3 Series EtherCAT
TM
Technical Manual
9-82
Subject to change without notice
www.asco.com/g3
Sub-bus Valve Module without Distribution
Used to control a distributed valve manifold through the Sub-Bus.
I/O Type
Status Bit Data Output Points
P580AEDS4010A00
NPN (Sinking) YES – Visual
128
BYTE Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
No. 7
No. 6
No. 5
No. 4
No. 3
No. 2
No. 1
No. 0
No. 23
No. 22
No. 21
No. 20
No. 19
No. 18
No. 17
No. 16
X+4
(Selectable)
No. 39
No. 38
No. 37
No. 36
No. 35
No. 34
No. 33
No. 32
X+5
(Selectable)
No. 47
No. 46
No. 45
No. 44
No. 43
No. 42
No. 41
No. 40
X+6
(Selectable)
No. 55
No. 54
No. 53
No. 52
No. 51
No. 50
No. 49
No. 48
X+7
(Selectable)
No. 63
No. 62
No. 61
No. 60
No. 59
No. 58
No. 57
No. 56
X+15
(Selectable)
No. 127
No. 126
No. 125
No. 124
No. 123
No. 122
No. 121
No. 120
32 additional coils available per each additional 32+ manifold driver board
