580 Series Sub-Bus Valve Module
10. COMM - 5 pin M12 male Sub-Bus communication connector.
o Must be connected to the SUB-BUS OUT connector of the previous assembly
o Carries 24 VDC power for electronics of module
11. POWER - 4 pin M12 male power connector.
o Power is required for Outputs
12. Used to distribute Valves on the Sub-Bus.
o Does not allow connection to G3 I/O modules.
Description Part Number
Sub-Bus Valve Module without I/O P580AEDS4010A00
