Emerson PACSystems RSTi-EP User Manual

User Manual Section 4
GFK-2958L May 2021
Detailed Descriptions of the Fieldbus Network Adapters 135
Class
Attribute
Get
Set
NV
1)
Data Type
2)
Name
Description
hex
dez
0x70
112
x
x
x
Array of 64
DWORD
Module Ref List
List of expected modules
0x71
113
x
x
x
BOOL
Diagnostic Alarm
Parameter “Diagnosis alarm”;
disabled (0) /
enabled (1)
0x72
114
x
x
x
BOOL
Process Alarm
Parameter “Process alarm”;
disabled (0) /
enabled (1)
0x73
115
x
x
Array of BYTE
Module Parameter
Array containing all parameter
of all modules
0x74
116
x
x
x
BOOL
Force Lock
Force mode: unlocked (0) /
locked (1)
0x75
117
x
x
x
BYTE
Behavior on Idle
Parameter “Behavior on idle
state “;
All outputs off (0) / Enable
substitute values
(1)/ Hold last value (2)
0x76
118
x
x
Array of 8 BYTE
Unacknowledged
Diagnosis
In the event of an
unacknowledged diagnosis
the Bit in for the respective
module is set
to 1 (Bit 0 for the first module of
the station,
Bit 63 for the 64th module).
Slot 0x65 (101)
Instance 0x00 (0)
0x64
100
x
UINT
Revision
Revision of this object
0x65
101
x
UINT
Max Instance
Highest possible instance of this
object
0x66
102
x
UINT
Number of Instances
Current number of instances
0x67
103
x
UINT
Max Class Attribute
ID of the last attribute of this
class in instance 0
Instances 0x01 ... 0x40 (1 ... 64)
0x64
100
x
x
USINT
Max Attributes
ID of the last instance attribute
0x65
101
x
STRING
Name
Name of the module
0x66
102
x
STRING
Product Code
Order number of the module
0x67
103
x
STRING
Serial Number
Serial number of the module
0x68
104
x
STRING
Module ID
ID of the module
0x69
105
x
STRING
Hardware Version
Hardware version of the module
0x6A
106
x
STRING
Software Version
Software version of the module
0x6B
107
x
STRING
MX Version
MX version of the module
0x6C
108
x
BYTE
Slot State
State of the module: 0x01: ok;
0x80: slot empty; 0x81: wrong
module;
0x82: diagnosis active
0x6D
109
x
UINT
Input Bit Length
Length of input data in Bit
