Emerson PACSystems RSTi-EP User Manual

User Manual Section 5
GFK-2958L May 2021
Detailed Description of I/O Modules 276
Specification
Description
For additional general data, refer to Section,
General Technical Data for I/O Modules.
5.21.3 Modifiable Parameters for EP-5422
Channel
Description
Options
Default
0 - 1
Period duration = n*0.02083
μ
s
1,202 ... 8,388,607
1,202
5.21.4 Diagnostic Data EP-5422
Name
Bytes
Bit
Description
Default
Error indicator
0
0
Module error
1
Internal error
2
External error
3
Channel error
0
4
Error
5
Reserved
0
6
Reserved
0
7
Parameter error
Module type
1
0
Module Type
0x0F
1
2
3
4
Reserved
0
5
Reserved
0
6
Reserved
0
7
Reserved
0
Error byte 2
2
0-7
Reserved
0
Error byte 3
3
0-2
Reserved
0
3
Internal diagnostic FIFO full
4-7
Reserved
0
Channel type
4
0-6
Channel type
0x72
7
Reserved
0
Diagnostic bits per
channel
5
Number of diagnostic bit per channel
0
Number of channels
6
Number of similar channels per module
2
Channel error
7-10
0-31
Reserved
0
Channel 0 error
to
Channel 31 error
11
to
42
0–7
Reserved
0
Time stamp
43-46
Time stamp [
μ
s] (32-bit)
5.21.5 Process† Data Inputs EP-5422
Byte
Format
Name
Bit
Function, if active
Remarks
IB0
Word
Channel 0:
Status word
IX0.0
reserved
IX0.1
Status PWM output
0: disabled, 1: enabled
IX0.2
reserved
