㩿㪈㪀
㩿㪉㪀
FRONT
Number
in
figure
Description
1Side
plate
2Screw
Figure
3-24
　　
Attaching
the
side
plate
11.
Attach
the
front
and
rear
doors
of
expansion
racks
1
and
2.
The
work
of
connecting
the
racks
ends
when
the
front
and
rear
doors
are
attached.
3.4 Mounting
the
Chassis
in
a
Rack
This
section
describes
the
procedures
for
mounting
the
chassis
in
an
equipment
rack.
The
method
of
securing
the
rails
differs
depending
on
the
rack
type.
As
described
in
this
section,
the
methods
of
securing
them
differ
between
the
racks
with
supporting
columns
having
angled
holes
and
the
racks
with
supporting
columns
having
M6
screw
holes.
For
rack
details,
see
the
manual
for
the
rack
used.
If
the
chassis
has
already
been
mounted
in
the
rack,
go
to
"3.5
Mounting
Optional
Components."
For
the
rack
mounting
procedure
of
each
chassis,
see
the
following
sections:
â–
Mounting
the
SPARC
M10-1
in
a
rack
â–
Mounting
the
SPARC
M10-4/SPARC
M10-4S
in
a
rack
â–
Mounting
the
PCI
expansion
unit
in
a
rack
Chapter
3
　
Installing
the
System 95
