㪘㪚㩷㪧㫆㫎㪼㫉㪄㫊㫌㫇㫇㫃㫐㩷㪽㪸㪺㫀㫃㫀㫋㫀㪼㫊
㪚㪙㪑㩷㪚㫀㫉㪺㫌㫀㫋㩷㪹㫉㪼㪸㫂㪼㫉
㪜㫏㫇㪸㫅㫊㫀㫆㫅㩷㫉㪸㪺㫂
PDU#1
AC3
PDU#1
AC2
PDU#1
AC1
PDU#1
AC0
PDU#0
AC3
PDU#0
AC2
PDU#0
AC1
PDU#0
AC0
CB
(*1)
(*3)
(*3)
(*3)
(*3)
(*3)
(*3)
(*3)
(*3)
(*1)
(*1)
(*1)
(*2)
(*2)
(*2)
(*2)
*1 For expansion rack 2, use PDU#3.
*2 For expansion rack 2, use PDU#2.
*3 Each PDU outlet is connected to the power cord shown in the figure. The system consumes no power when
there is no device connected to the PDU outlets. For the wiring of power cords within the expansion
rack, see
Figure 2-27.
Figure 2-17
Power supply system with redundant power supply connections
(expansion rack)
2.8.2 Dual power feed
Dual power feed is an option for receiving power feeds from two external power
supplies. If a failure occurs in one external power supply, the system can still
continue to operate with the external power supply on the other system.
Figure 2-18, Figure 2-19, and Figure 2-20 show power supply
systems with dual
power feed.
For dual system connections, connect the power cords to the input power supplies on
Chapter 2 Planning and Preparing for System Installation 45
