Fujitsu M10 User Manual

Chapter 5
Connecting Cables to the Chassis
This chapter describes the procedure for connecting the power cords, serial cable,
and network cables to each chassis. All ports for the connections are on the rear of the
chassis. For a description of each port, see "2.10 Checking External Interface Port
Specifications."
■
Connecting Cables to the SPARC M10-1
■
Connecting Cables to the SPARC M10-4/SPARC M10-4S
■
Connecting Cables to the PCI Expansion Unit
■
Connecting Cables to a Crossbar Box
■
Storing Cables
5.1 Connecting Cables to the SPARC
M10-1
This section describes the procedure for connecting the serial cable, network cables,
and power cords to the SPARC M10-1.
1.
Connect the serial cable supplied with the chassis from the serial port of the
XSCF unit (A in Figure 5-1) to the system management terminal.
