Fujitsu M10 User Manual

Table 6-1
Terminal software setting value (continued)
Setting item Value
STOP bit 1 bit
Flow control None
Delay Other than 0
Note -
For direct connections between chassis, BB#00 is usually the master XSCF, and BB#01
is the standby XSCF. For connections through crossbar boxes, XBBOX#80 is usually the
master XSCF, and XBBOX#81 is the standby XSCF. If the master is switched, BB#01 or
XBBOX#81 becomes the master XSCF, and BB#00 or XBBOX#80
becomes the standby XSCF.
For the mounting locations of BB#00 and BB#01, see Figure 2-3 in "2.4.1 Mounting
conditions for general racks."
Note -
If a BB-ID is not set or incorrectly set when the input power is turned on, the XSCF
does not start normally. Therefore, confirm that the BB-ID settings are correct.
2.
Confirm that the system management terminal is connected to the serial port
of the chassis.
For a building block configuration, confirm that the terminal is connected to the
serial port of the master XSCF.
6.2 Turning On the Input Power
This section describes the procedures for connecting the power cords to outlets,
turning on the input power, and starting the XSCF.
6.2.1 Checking the BB-ID settings (for the SPARC
M10-4S)
For the SPARC M10-4S, confirm that the BB-IDs are set properly before turning on
the input power.
1.
Check the BB-IDs on the operation panel on the front of the SPARC M10-4S
chassis.
Confirm that BB-IDs 00 to 15 are set sequentially.
2.
Check the BB-IDs on the operation panel on the front
of the cross bar box
chassis.
Confirm that BB-IDs 80 to 83 are set sequentially.
For details on setting them, see "4.1 Setting the ID (BB-ID) Identifying a Chassis."
Fujitsu M10/SPARC M10 Systems Installation Guide
･
July 2015178
