Fujitsu M10 User Manual

Chapter 10
Removing a System with a Building
Block Configuration
This chapter describes the procedure for removing the SPARC M10-4S in a building
block (BB) configuration.
For the removal procedure, see the relevant section corresponding to a removal
pattern shown in "8.3 Confirming the Removal Pattern of a Building Block
Configuration."
■
Preparing the Necessary Tools for Removal
■
Removing the SPARC M10-4S
■
Removal of Expansion Rack 2, and Decrease in the Number of SPARC M10-4S
Units to Four or Less
10.1 Preparing the Necessary Tools for
Removal
The tools used to remove the SPARC M10-4S are the same as those for initial
installation. See "3.1 Preparing the Necessary Tools/Information for Installation."
Before starting removal work, be sure to see "8.3.2 Points of concern during removal."
10.2 Removing the SPARC M10-4S
This section describes the procedure for removing only the SPARC M10-4S. This
procedure corresponds to pattern A and pattern B in Figure 8-3.
The SPARC M10-4S is removed in either of the following two ways: removal while
the physical partition (PPAR) is operating, or removal by stopping only the physical
partition
that includes the SPARC M10-4S to be removed.
To change all SPARC M10-4Ss to a 1BB configuration as shown in pattern B (2) in
Figure 8-3, stop all the physical partitions and then perform removal.
The physical partition number must match the BB-ID value of one of the SPARC
277
