Appendix B
Cable Connection Information on
Building Block Configurations
This appendix provides cable connection routing diagrams and cable configuration
lists for each building block configuration.
■
2BB Configuration (Direct Connections between Chassis)
■
3BB Configuration (Direct Connections between Chassis)
■
4BB Configuration (Direct Connections between Chassis)
■
2BB Configuration to 8BB Configuration (Connections through Crossbar Boxes)
■
9BB Configuration to 16BB Configuration (Connections through Crossbar Boxes)
B.1 2BB Configuration (Direct Connections
between Chassis)
The numbers enclosed in parentheses in Figure B-1 indicate the connection order. For
details, see Table B-1.
323
