Note -
The default BB-ID value is 00. There are cases where each BB-ID is set by the factory at
the time of shipping. A BB-ID has been set for any chassis that is shipped mounted in a rack.
Note -
When connecting the SPARC M10-4S used as a standalone unit to a building block
configuration, execute the restoredefaults command to return to the factory defaults before
setting a BB-ID for it.
Chapter 4
Configuring Building Block
Connections
This chapter describes the procedures for setting the chassis IDs required in building
block connection and for connecting cables between each chassis.
The work described in the chapter is performed only for the SPARC M10-4S.
■
Setting the ID (BB-ID) Identifying a Chassis
■
Connecting Cables (for Direct Connections between Chassis)
■
Connecting Cables (for Connections through Crossbar Boxes)
4.1 Setting the ID (BB-ID) Identifying a
Chassis
This section describes the setting of the ID (referred to below as BB-ID) required for
identifying each chassis in the system.
Set BB-IDs sequentially from 00.
See the following and check the mounting locations and BB-ID setting values of
chassis.
- For direct connections between chassis: seeFigure 2-3 of "2.4.1 Mounting
conditions for general racks".
- For connections through crossbar boxes: see Figure 2-9 of "2.4.3 Mounting
conditions for expansion racks".
1.
Set a BB-ID for the SPARC M10-4S.
Set the BB-ID by operating the BB-ID switch on the operation panel on the front
of the chassis. Set SPARC M10-4S BB-IDs sequentially
from 00 to 15.
143
