A
Note
-
For
an
expansion
rack,
crossbar
cables
(optical)
and
XSCF
cables
are
stored
in
the
rack
at
the
time
of
shipping,
so
this
work
is
not
necessary.
Figure
5-13
　　
Serial
port
location
2.
Confirm
that
the
SPARC
M10-4S
and
crossbar
box
power
cords
are
connected
to
the
PDUs
of
the
expansion
rack.
The
SPARC
M10-4S
and
crossbar
box
power
cords
are
shipped
connected
to
the
PDUs
of
the
expansion
rack.
If
the
SPARC
M10-4S
has
been
mounted
on
site,
connect
the
power
cords
to
the
PDUs
at
this
time.
3.
Confirm
that
the
CB
switches
of
the
PDUs
of
the
expansion
rack
are
OFF.
5.5 Storing
Cables
This
section
describes
the
procedure
for
storing
the
cables
connected
to
the
SPARC
M10-4/SPARC
M10-4S
in
a
rack.
The
procedures
for
storing
the
cables
in
the
rack
are
described
separately
for
the
rack
widths
of
700
mm
and
600
mm.
Check
your
rack
before
performing
this
work.
5.5.1 Rack
with
a
width
of
700
mm
(27.6
in.)
For
a
rack
with
a
width
of
700
mm
(27.6
in.),
keep
the
power
cords
together
at
the
left
side
and
the
other
cables
at
the
right
side,
as
viewed
from
the
rear
of
the
rack.
1.
Hang
the
power
cords
from
the
left
side
as
viewed
from
the
rear
of
the
rack.
Place
the
power
cords
over
the
cable
support
fixing
bracket
(A
in
Figure
5-14)
to
hang
them
there
as
is.
Fujitsu
M10/SPARC
M10
Systems
Installation
Guide
･
July
2015172
