Table 2-2
Physical specifications of each chassis
Item SPARC M10-1 SPARC M10-4 SPARC M10-4S Expansion rack PCI expansion
unit
Height 42.5 mm
(1.7 in.)
(1U)
175 mm
(6.9 in.)
(4U)
175 mm
(6.9 in.)
(4U)
2,000 mm
(78.7 in.)
86 mm
(3.4 in.)
(2U)
Width 431 mm
(17.0 in.)
440 mm
(17.3 in.)
440 mm
(17.3 in.)
700 mm
(27.6 in.)
440 mm
(17.3 in.)
Depth 721 mm
(28.4 in.)
746 mm
(29.4 in.)
810 mm
(31.9 in.)
1,050 mm
(41.3 in.)
750 mm
(29.5 in.)
Weight 18 kg 58 kg 60 kg 780
kg 22 kg
2.3.1 Size and weight
Table 2-2 lists the size and weight of each chassis.
2.4 Confirming Rack Specifications
Use a rack that meets the specified conditions for using the SPARC M10-1 or SPARC
M10-4 in a standalone configuration or using the SPARC M10-4S in a configuration
up to the 4BB configuration (direct connections between chassis).
If the SPARC M10-4S will be used with connections through crossbar boxes, an
expansion
rack with crossbar boxes mounted must be ordered.
The expansion racks are divided according to expandability as expansion rack 1 and
expansion rack 2. For a configuration with up to 8 units connected, an order for
expansion rack 1 is necessary. For a configuration with 9 to 16 units connected, an
additional order for expansion rack 2 is necessary.
This section describes the items that must be confirmed to use a rack
2.4.1 Mounting conditions for general racks
This section describes the rack mounting conditions for each system configuration.
Chapter 2 Planning and Preparing for System Installation 23
