Note -
Do not connect to an outlet at this point.
Note -
Ensure that the FC cable, when secured, has a bend radius of 30 mm (1.2 in.) or more.
Note -
In a building block configuration with direct connections between chassis, BB#00 is
usually the master XSCF, and BB#01 is the standby XSCF.
If the master is switched, BB#01 becomes the master XSCF, and BB#00 becomes the standby
XSCF.
Note -
In a building block configuration with connections through crossbar boxes, the system
operates with batch operations by the master XSCF of the crossbar box. No serial cable is
connected to the SPARC M10-4S.
5.
Secure cables to the CMA.
a. Pull out the chassis until the CMA is fully extended.
b. Bundle cables such as the power cords, LAN cables, and FC cables, and
secure them with the cable clamp on the CMA.
c. Put the chassis back into the rack.
6.
Check the movement of the
CMA.
a. Pull out the chassis slowly to check whether it moves smoothly.
b. Confirm that the laid cables are not twisted.
5.2 Connecting Cables to the SPARC
M10-4/SPARC M10-4S
This section describes the procedure for connecting the serial cable, network cables,
and power cords to the SPARC M10-4/SPARC M10-4S.
1.
Connect the serial cable supplied with the chassis from the serial port of the
XSCF unit (A in Figure 5-4) to the system management terminal.
In a building block configuration, the
system operates with batch operations by
the chassis of the master XSCF. Connect the serial cable to the master XSCF.
Chapter 5 Connecting Cables to the Chassis 165
