Fujitsu M10 User Manual

B
A
A
A
Note -
Do not pull it out with a hold on the cable. Doing so prevents the connector lock from
Figure 4-7
Removing the blank panel
Figure 4-8
Mounting the crossbar unit
2.
Move the crossbar cables (optical) of XBBOX#80/#8 1.
a. Remove the crossbar cables from L4 to L7 and from R4 to R7 of crossbar unit
#1 (see Figure 4-9). Hold the tab (A in Figure 4-10) of the crossbar cable
(optical) and pull it straight out in the direction of the arrow to remove the
cable.
Chapter 4 Configuring Building Block Connections 149
