15-1
15. NAVIGATION TOOLS
This chapter presents the various navigation tools available with the system. With the
exception of the mini conning display and the divider, the tools listed below are in the
[Overlay/NAV Tools] box.
• TT/AIS (see chapters 3 and 4)
• Parallel index lines
• Check area
• Range rings
• Predictor
• Anchor watch
• Under keel clearance
• Mini conning display
• Divider
15.1 How to Access the Nav Tools in the Overlay/NAV
Tools Box
The [Overlay/NAV Tools] box is located at bottom-right position on the screen. Use the
page selection buttons to select desired page.
[Overlay/NAV Tools] box ([CheckArea] page)
Page
selection
buttons
Minimize button
Page name
To Next Page
