22. SETTINGS MENU
22-5
22.5 Self Test
The [Self Test] page is mainly for use by the service technician to check the equip-
ment. The chart radar is inoperative during the test.
No. Name Description
1 Test results, pro-
gram numbers
The results of the self test and the program numbers.
(xx=version number)
2 [Start] button Start the self test.
3 [Stop] button Stop the self test. (Shown during test.)
[EC-3000]
RADAR Software Version: 0359266-02.xx
[Radar Sensor]
SPU Software Version: 0359281-01.xx
[key1]
Software Version: 2450086-01.xx
[Dongle Information]
Function: ecdis,radar
ENC User Permit: ERROR
ARCS User Permit: ERROR
ARCS PIN: ERROR
1
2
3
To Next Page
