Loading...What to do if I get PLC timeout errors on my GE VersaMax PLC Controller?
PLC Timeout Errors can occur due to heavy SRTP traffic, long PLC sweep time or PLC Communication Window set to LIMITED mode. To resolve this: * Reduce the size, number, or frequency of SRTP requests at the remote SRTP client. * Modify the PLC application to reduce the PLC sweep time. * Change to RUN-TO-COMPLETION mode.
Why does my GE VersaMax PLC Controller have unexpected Ethernet restarts or runtime errors?
Unexpected Ethernet Restart or Runtime Errors may happen because sustained heavy EGD and/or SRTP operation can exceed the data transfer and processing capacity of the CPUE05, especially when the CPUE05 is connected to a repeater-type network hub. Consider these solutions: * Replace the repeater-type hub with a switching-type network hub. * Reduce the number, size, or frequency of the EGD exchanges and/or transfers over SRTP connections.
What to do if I get receive resource exhaustion errors on my GE VersaMax PLC?
Receive resource exhaustion errors occur when heavy EGD traffic exhausts network data buffers or bursts of heavy network traffic are received at the CPUE05. To fix this, you can modify the application to reduce the number, size, or frequency of produced and consumed EGD exchanges. Alternatively, analyze the broadcast and multicast network traffic received at the CPUE05 and reduce such traffic if possible.
How to fix EGD configuration mismatch errors on a GE VersaMax PLC?
General| Model | VersaMax |
|---|---|
| Type | Programmable Logic Controller (PLC) |
| I/O Points | Varies by configuration |
| Communication Protocols | Ethernet, Profibus, Modbus, Serial |
| Communication Ports | RS-232, RS-485, Ethernet |
| Programming Languages | Ladder Logic, Function Block Diagram, Structured Text |
| Programming Software | Proficy Machine Edition |
| Power Supply | 24V DC or 100-240V AC |
| Certifications | UL, CE, cUL |
Introduces the VersaMax product line, its features, and applications.
Details the different CPU modules available for VersaMax PLCs and their specifications.
Describes the power supply options and requirements for VersaMax systems.
Lists and describes the various Input/Output (I/O) modules available for VersaMax PLCs.
Explains the different types of carriers used for mounting VersaMax modules.
Details the types and usage of expansion modules for VersaMax I/O systems.
Lists and describes the communication modules that enhance VersaMax system flexibility.
Outlines the key features and capabilities of the CPU001, CPU002, and CPU005 modules.
Provides detailed technical specifications for the CPU001, CPU002, and CPU005 modules.
Covers general environmental and EMC specifications applicable to VersaMax products.
Describes the serial port configurations, capabilities, and cable lengths for CPU modules.
Explains the function and operation of the CPU module's mode switch.
Details the meaning and function of the various LEDs on the CPU module.
Describes the memory allocation for CPU modules and its configurable aspects.
Lists the features of the CPUE05 CPU module, including its Ethernet interface.
Provides detailed technical specifications for the CPUE05 CPU module.
Covers general environmental and EMC specifications applicable to VersaMax products.
Details the serial port configurations for the CPUE05, including port usage and protocols.
Describes the Ethernet LAN port capabilities, connection standards, and auto-selection.
Explains the function and operation of the CPUE05 module's mode switch.
Details the meaning of the LEDs on the CPUE05 module indicating status and activity.
Explains the functions of the Ethernet Restart pushbutton on the CPUE05 module.
Describes the status and activity indicated by the Ethernet interface LEDs.
Details the configurable user memory for the CPUE05 module and its allocation.
Provides an overview of the CPUE05's Ethernet interface capabilities and features.
Provides guidelines for mounting VersaMax modules and carriers on DIN rails or panels.
Details the procedure for installing an Expansion Transmitter Module.
Explains how to install an Expansion Receiver Module into an expansion rack.
Covers the installation process for Power Supply modules onto CPUs, Expansion Receivers, or carriers.
Describes how to add I/O and option modules to a VersaMax rack.
Explains how to activate or replace the backup battery for the CPU module.
Details serial port connections, including cable lengths and available pre-assembled cables.
Provides instructions for connecting the CPUE05 module to a 10BaseT Ethernet network.
Outlines requirements for surge, ESD, and FTB protection for CE Mark compliance.
Explains the two methods for configuring VersaMax PLCs: autoconfiguration and programmer configuration.
Describes the convention of racks and slots used for module identification in VersaMax systems.
Details the process of creating and applying a customized configuration using software.
Explains how the CPU automatically generates a configuration based on installed modules.
Provides an overview of the configuration steps for the VersaMax Ethernet interface.
Details the essential Ethernet interface parameters like IP address, subnet mask, and gateway.
Explains how to configure Ethernet Global Data exchanges between devices.
Guides on configuring Ethernet Global Data exchanges from a producer's perspective.
Guides on configuring Ethernet Global Data exchanges for consumers, including selective consumption.
Covers the configuration of advanced operating parameters for the Ethernet interface.
Breaks down the sequence of operations performed by the CPU during a sweep cycle.
Describes the normal operating mode of the PLC CPU and its sweep execution.
Explains the different CPU stop modes: I/O Disabled and I/O Enabled.
Details functions used to control program execution flow, like CALL, END, and JUMP.
Explains how the Run/Stop mode switch affects CPU operation and memory protection.
Covers password protection and privilege levels for accessing PLC features.
Describes the fundamental structure of an application program within the PLC.
Explains the concept of subroutines and how they simplify programming.
Introduces the program languages supported, including Ladder Diagram and SFC.
Provides a reference to the various instructions and functions available in the PLC's instruction set.
Explains how data is stored and referenced in the PLC's memory.
Describes which data types are retentive and how their states are preserved.
Details the system status references (%S, %SA, %SB, %SC) and their definitions.
Explains how program functions handle numerical data types like REAL, INT, and DINT.
Describes time-tick contacts used for providing regular pulses in program functions.
Covers functions for manipulating bits, including logical operations and shifts.
Details functions that control program execution, such as CALL, END, and MCR.
Explains functions used for moving data between different memory locations.
Describes functions for converting data between different numerical types.
Covers mathematical and numerical operations like add, subtract, trig, and logs.
Explains functions for comparing numbers and checking values against ranges.
Details the basic relay functions, including contacts and coils for logic control.
Covers functions for array manipulation, including copying and searching.
Describes timer and counter functions used for timing and counting operations in programs.
Lists the function numbers and descriptions for various Service Request (SVCREQ) operations.
Explains the general format and parameters for using SVCREQ functions.
Details how to change or read the Constant Sweep Timer settings using SVCREQ 1.
Explains how to read the times for programmer and system communications windows using SVCREQ 2.
Describes how to change the mode of the programmer communications window using SVCREQ 3.
Explains how to change the system communications window mode using SVCREQ 4.
Details how to read or change the number of words for program checksumming using SVCREQ 6.
Covers reading or changing the PLC's time-of-day clock using SVCREQ 7.
Explains how to reset the watchdog timer during a sweep using SVCREQ 8.
Describes how to read the elapsed time since the sweep start using SVCREQ 9.
Explains how to read the name of the currently executing folder using SVCREQ 10.
Details how to read the PLC ID of the executing PLC using SVCREQ 11.
Explains how to stop the PLC at the end of the next sweep using SVCREQ 13.
Describes how to clear the PLC fault table or I/O fault table using SVCREQ 14.
Explains how to read the last logged entry from the fault tables using SVCREQ 15.
Details how to read the system's elapsed time clock using SVCREQ 16.
Explains how to check for I/O overrides in the CPU's %I and %Q memories using SVCREQ 18.
Covers reading master checksums of the application program and configuration using SVCREQ 23.
Explains how to reset the Ethernet daughterboard from ladder logic using SVCREQ 24.
Details how to check installed modules against software configuration using SVCREQ 26/30.
Explains how to read the elapsed time between power-down and power-up using SVCREQ 29.
Explains the format and parameters of the Communication Request (COMMREQ) function.
Provides tables for command block values required for setting up Serial Ports using COMMREQ.
Discusses how Serial I/O COMMREQs are called from the PLC sweep and their compatibility.
Lists and describes various Serial I/O COMMREQ commands for port management.
Provides an overview of the Ethernet interface capabilities for VersaMax CPU model IC200CPUE05.
Explains IP address structure, classes, and formats used in Ethernet networks.
Describes the role of routers in connecting networks and facilitating communication.
Details Ethernet Global Data (EGD) for efficient data transfer between devices.
Lists tools and methods for diagnosing Ethernet operation and EGD problems.
Provides solutions for common Ethernet errors like timeout, restarts, and configuration mismatches.
Describes the operands and parameters used by the PID function block.
Details the reference array parameters used for configuring the PID function.
Explains how the PID function operates in Automatic and Manual modes.
Covers PID algorithm selection, gain calculations, and error term configurations.
Guides on determining process characteristics for PID loop tuning.
Provides methods for setting and tuning PID loop gains for optimal performance.
Details how to read, write, or verify data using the EZ Program Store device with a programmer.
Explains how to update a PLC CPU using the EZ Program Store device without a programmer.
Presents base sweep time data for various VersaMax CPU models.
Shows typical sweep impact times for boolean instructions on CPU models.
Details sweep impact times and size information for supported CPU function blocks.
Lists the user logic space consumed by exponential, radian, and relational functions.
Lists the user logic space consumed by bit operations and data move functions.
Details the user logic space consumed by table functions like Array Move and Search.
Lists the user logic space consumed by conversion and control functions.
Provides typical scan times for various I/O modules based on their type and location.
Shows scan times for modules installed in the main PLC rack for different CPU types.
Presents scan times for modules in single-ended expansion racks for different CPU types.
Shows scan times for modules in multiple remote expansion racks for different CPU types.
Provides scan times for modules in single-ended isolated expansion racks for different CPU types.
Analyzes the impact of Ethernet Global Data exchanges on CPU sweep time.
Discusses the system's capacity for large Ethernet Global Data configurations.
