Sizes of Bit Operations, Data Move Functions
The size of a function is the number of bytes consumed in user logic space for each
instance of the function in a ladder diagram application program.
Group
Function
CPU001/002 CPU005/E05
Increment Size
Enabled Disabled Enabled Disabled
Bit
Logical AND
60 12 50 10
–
13
Operation Logical OR
60 12 50 10
–
13
Logical Exclusive OR
60 12 50 10
–
13
Logical Invert, NOT
50 12 40 10
–
10
Shift Bit Left 134 12 80 10 14.78 16
Shift Bit Right
129 12 80 10 16.31 16
Rotate Bit Left 110 12 70 10 18.45 16
Rotate Bit Right
111 12 70 10 18.41 16
Bit Position 76 12 57 10
–
13
Bit Clear 70 12 56 10
–
13
Bit Test 60 12 44 10
–
13
Bit Set 70 12 56 10
–
13
Mask Compare (WORD)
158 12 110 10
–
25
Mask Compare (DWORD)
150 12 100 10
–
25
Bit Sequencer
150 109 101 77 0.24 16
Data Move
Move (INT)
45 12 32 10 2.83 10
Move (BIT)
80 12 60 10 10.76 13
Move (WORD)
46 12 32 10 2.82 10
Move (REAL)
60 12 47 10 2.75 13
Block Move (INT)
60 12 50 10
–
28
Block Move (WORD)
60 12 50 10
–
28
Block Move (REAL)
113 12 94 10
–
13
Block Clear 100 12 83 10 4.63 11
Shift Register (BIT)
130 12 94 10 0.45 16
Shift Register (WORD)
120 12 100 10 2.76 16
COMM_REQ *
175 175 120 120
–
13
Appendix A Performance Data GFK-1503E User Manual 305
