Modules Located in Single-ended Isolated Expansion

Rack

The table below shows timing for modules located in an expansion rack in a single-ended

expansion system that has an Isolated Expansion Receiver Module (IC200ERM001) in

the expansion rack and an Expansion Transmitter module (IC200ETM001) in the CPU

rack.

Module Type

CPU005/CPUE05 CPU001/CPU002

Isolated Rack Isolated Rack

Input Output Input Output

Discrete Input Type 1

†

466

—

524

—

Discrete Input Type 2

†

869

—

913

—

Discrete Output Type 1

†

—

452

—

496

Discrete Output Type 2

†

—

837

—

875

Discrete Output w/ ESCP Per Point

Fault Reporting

—

850

—

914

Intelligent Discrete Input 20 Points

4050

—

4086

—

Intelligent Discrete Output 12 Points

—

5135

—

5135

Analog Input 4 Channels

2054

—

2093

—

Analog Input 8 Channels

3660

—

3660

—

Analog Input 15 Channels

6471

—

6471

—

Analog Output 2 Channels

—

1221

—

1251

Analog Output 4 Channels

—

1991

—

2021

Analog Output 8 Channels

—

3531

—

3560

Analog Output 12 Channels

—

5071

—

5099

Intelligent Analog Input 4 Channels

3155

—

3196

—

Intelligent Analog Input 7 Channels

3401

—

3444

—

Intelligent Analog Input 8 Channels

3483

—

3526

—

Intelligent Analog Output 4 Channels

—

2751

—

2811

PLC Network Comm Profibus-DP

Slave

†† †† †† ††

DeviceNet Network Master/Slave

†† †† †† ††

†

Mixed modules have both and input and output scan time values.

††

Network Communications Modules (NCM) Scan Impact Times vary depending upon the network

configuration.

Appendix A Performance Data GFK-1503E User Manual 313
