3.2 Module Specifications
Size
4.95” (126mm) x 5.04” (128mm)
Program storage System flash, battery-backed RAM
Battery backup for program, data, and
time-of-day clockl
Super capacitor provides power to memory for 1 hour
Over 1 hour, backup battery protects memory contents up to 6 months.
Backup battery has shelf life of 5 years when not in use.
Backplane current consumption:
no serial port converter or EZ
Program Store device
5V output: 100mA
3.3V output:
820mA
†
IC200CPUE05
with serial port converter or EZ
Program Store device
5V output: 200mA
Floating point
yes
Boolean execution speed 0.5ms/K (typical)
Realtime clock accuracy (for timer
functions)
100ppm (0.01%) or +/- 9sec/day
Time of day clock accuracy
23ppm (0.0023%) or +/- 2sec/day @ 30C.
100 ppm (0.01%) or +/- 9sec/day @ full temperature range
Embedded communications
RS-232, RS-485, Ethernet interface
Configurable memory 128K bytes maximum
Ethernet Interface Specifications
Number of SRTP server connections 8
Ethernet data rate
10Mbps
Physical interface
10BaseT RJ45 Shielded
WinLoader support via CPU port
Number of Ethernet Global Data
configuration-based exchanges
32
EGD Exchange limits
100 data ranges and 1400 bytes of data per exchange; 1200 total data ranges
across all exchanges.
Time Synchronization NTP - client only (Supported IC200CPUE05-HK or before)
Selective Consumption of EGD
yes
Load EGD configuration from PLC to
programmer
yes
Remote Station Manager over UDP
yes
Local Station Manager (RS-232) via CPU port
Configurable Advanced User Parameters
yes
†
CPUE05 requires a power supply with expanded 3.3V.
CPU Module Datasheet: CPUE05 GFK-1503E User Manual 41
