2.3 VersaMax General Product Specifications
VersaMax products should be installed and used in conformance with product-specific
guidelines as well as the following specifications:
Environmental
Vibration IEC68-2-6
1G @57-150Hz, 0.012in p–p @10-57Hz
Shock IEC68-2-27
15G, 11ms
Operating Temp. 0 deg C to +60 deg C ambient
Storage Temp. -40 deg C to +85 deg C
Humidity 5% to 95%, noncondensing
Enclosure Protection IEC529
Steel cabinet per IP54:
protection from dust & splashing water
EMC Emission
Radiated, Conducted
CISPR 11/EN 55011
Industrial Scientific & Medical Equipment
(Group 1, Class A)
CISPR 22/EN 55022
Information Technology Equipment (Class A)
FCC 47 CFR 15
referred to as FCC part 15,
Radio Devices (Class A)
EMC Immunity
Electrostatic Discharge
EN 61000-4-2
8KV Air, 4KV Contact
RF Susceptibility
EN 61000-4-3
10Vrms /m, 80Mhz to 1000Mhz, 80% AM
ENV 50140/ENV 50204
10Vrms/m, 900MHz +/-5MHZ
100%AM with 200Hz square wave
Fast Transient Burst EN 61000-4-4
2KV: power supplies, 1KV: I/O, communication
Surge Withstand
ANSI/IEEE C37.90a
Damped Oscillatory Wave: 2.5KV power supplies,
I/O [12V-240V]; 1KV communication
IEC255-4
Damped Oscillatory Wave: Class II,
power supplies, I/O [12V-240V]
EN 61000-4-5
2 kV cm(P/S); 1 kV cm (I/O and communication
modules)
Conducted RF EN 61000-4-6
10Vrms, 0.15 to 80Mhz, 80%AM
Isolation
Dielectric Withstand
UL508, UL840, IEC664
1.5KV
Power Supply
Input Dips, Variations
EN 61000-4-11
During Operation: Dips to 30% and 100%, Variation
for AC +/-10%, Variation for DC +/-20%
CPU Module Datasheets: CPU001, CPU002, CPU005 GFK-1503E User Manual 33
