Appendix A Performance Data
This section presents performance data collected on the VersaMax CPUs IC200CPU001,
CPU002, CPU005, and CPUE05. The data includes base sweep time, sweep impact of
boolean instructions, function block sweep impact times, function block sizes, and I/O
module scan time data.
Base Sweep Time
The table below shows the base sweep time with the default program in Run mode, no I/O
modules present or configured, and no serial connections to either serial port.
Model
Time (in milliseconds)
CPU001/002 1.605
CPU005 1.039
CPUE05 1.91
Boolean Instruction Time
This table shows the typical sweep impact time for boolean instructions:
Model
Typical Time (in microseconds)
CPU001/002 1.7
CPU005/E05 0.8
Appendix A Performance Data GFK-1503E User Manual 301
For public disclosure
