Modules Located in Multiple Remote Expansion Rack

The table below shows timing for modules located in the expansion racks of a

multiple-rack expansion system that uses only Isolated Expansion Receiver Modules

(IC200ERM001). In this type of system, there is an Expansion Transmitter module

(IC200ETM001) in the CPU rack.

Module Type

CPU005/CPUE05 CPU001/CPU002

Multiple Remote Rack Multiple Remote Rack

Input Output Input Output

Discrete Input Type 1

†

130

—

193

—

Discrete Input Type 2

†

181

—

258

—

Discrete Output Type 1

†

—

118

—

167

Discrete Output Type 2

†

—

165

—

223

Discrete Output w/ ESCP Per Point

Fault Reporting

—

177

—

261

Intelligent Discrete Input 20 Points

651

—

766

—

Intelligent Discrete Output 12 Points

—

728

—

757

Analog Input 4 Channels

324

—

393

—

Analog Input 8 Channels

541

—

646

—

Analog Input 15 Channels

920

—

1087

—

Analog Output 2 Channels

—

206

—

267

Analog Output 4 Channels

—

300

—

377

Analog Output 8 Channels

—

489

—

596

Analog Output 12 Channels

—

678

—

815

Intelligent Analog Input 4 Channels

442

—

535

—

Intelligent Analog Input 7 Channels

484

—

582

—

Intelligent Analog Input 8 Channels

497

—

598

—

Intelligent Analog Output 4 Channels

—

490

—

615

PLC Network Comm Profibus-DP

Slave

†† †† †† ††

DeviceNet Network Master/Slave

†† †† †† ††

†

Mixed modules have both and input and output scan time values.

††

Network Communications Modules (NCM) Scan Impact Times vary depending upon the network

configuration.

312 GFK-1503E VersaMax PLC User Manual
