2.9 KPI energy / heat recovery unit
2.9.1 Accessories supplied with the unit
Check that the following accessories are supplied with the unit.
N O T E
Please contact your HITACHI distributor if any of the accessories has not been supplied with the unit.
Accessory Appearance Quantity Purpose
Duct adapter 4 For duct connection.
Set screw (M4 x 8) 24 –
Adapter gasket 4 For hose connection.
Anti-vibration rubber, nut,
washer and spring washer
4, 4, 4, 8 For unit installation.
2.9.2 Unit installation
Initial checks
KPI-(252-802)(E/H)2E energy / heat recovery unit
1. Unit inspection and maintenance access.
KPI-(1002-2002)(E/H) energy / heat recovery unit
1. Unit inspection and maintenance access.
2 Unit installation
61
SMGB0063 rev. 1 - 10/2010
