Honeywell 8680i User Manual

206 8680i User Guide
Text Color - Foreground Line 1
GUITCU
This command uses a hex string to set the foreground color of the display text for
line 1.
Valid values are 00-FF. Default = FFFFFF (white).
Sample
char cClrMenuString[] = "\x16M\x0DGUITCUFFFFFF.";
SynMenuCmdSync(cClrMenuString);
Text Color - Foreground Line 2
GUITCD
This command uses a hex string to set the foreground color of the display text for
line 2.
Valid values are 00-FF. Default = FFFFFF (white).
Sample
char cClrMenuString[] = "\x16M\x0DGUITCDFFFFFF.";
SynMenuCmdSync(cClrMenuString);
Text Color - Background
GUITBC
This command uses a hex string to set the background color of the display text.
Byte Value
0Red
1Green
2 Blue
Byte Value
0Red
1Green
2 Blue
Byte Value
0Red

Honeywell 8680i Specifications

General

Type	Wearable bar code reader
Sensor type	-
Scanner type	1D/2D
Pitch reading angle	-45 - 45 °
Motion tolerance (cm/s)	584
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	Code 39, PDF417, U.P.C.
2D (matrix & stacked) barcodes supported	Data Matrix, PDF417
Bluetooth version	4.1
Standard interfaces	Bluetooth
Connectivity technology	Wireless
Product color	Black
Built-in display	No
International Protection (IP) code	IP54
Charging time	4 h
Battery voltage	3.6 V
Power source type	Battery
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	81 mm
Width	56 mm
Weight	- g

Summary

Chapter 1 - Get Started

8680i Overview and Attachment

Details the 8680i components and how to attach it to a triggered ring wearable accessory.

Battery and Charging

Covers battery replacement, recommendations, disposal, and charging procedures.

Connecting to Networks and Devices

Instructions for connecting the 8680i to various Bluetooth devices and networks.

Configuration Defaults

Guides on setting and resetting custom default configurations for the scanner.

Chapter 2 - Wireless System Operation

Chapter 5 - Data Format

Data Format Management

Procedures for adding, clearing, and saving data formats.

Chapter 6 - Symbologies

Chapter 7 - Imaging Commands

Image Snap and Modifiers

Capturing images with options for imaging style, beeper, trigger, and LEDs.

Image Ship and Modifiers

Sending captured images with options for filters, compensation, and pixel depth.

Intelligent Signature Capture (IMGBOX)

Configuring signature capture area size, location, and image parameters.

Chapter 8 - Utilities

Reset Factory Defaults

Procedure to erase settings and restore the 8680i to original factory defaults.

Chapter 9 - Serial Programming Commands

Reset Custom Defaults

Restores the 8680i to custom default settings or factory defaults.

Chapter 11 - Product Specifications

8680i Mobile Computer Specifications

Detailed mechanical and electrical specifications for the 8680i scanner.

Chapter 12 - Maintenance and Troubleshooting

Troubleshooting Common Issues

Guidance on resolving issues like symbol reading errors and data entry problems.
