Honeywell 8680i User Manual

8680i User Guide 13
The Bluetooth symbol appears in the scanner window when the scanner pairs with
a host.
Pair with a PC or Laptop Bluetooth: HID Keyboard Mode
In this mode, the 8680i pairs with a Bluetooth device using a HID keyboard.
1. Scan a Bluetooth HID Keyboard Connect bar code below.
2. Set your host device so it searches for other Bluetooth devices. (Refer to your
host device’s User’s Guide for pairing instructions.)
3. Once your host device has located the scanner, select the 8680i scanner name
from the list displayed.
Note: See Enter a Bluetooth PIN on page 15 if your host device displays a PIN.
The Bluetooth symbol appears in the scanner window when the scanner pairs with
a host.
Disconnect from the Host
Once your scanner has been connected to a host, you must disconnect it in order
to communicate with a different device. Scan the Bluetooth Disconnect bar code
to unlink the scanner from the currently linked host.
* Bluetooth HID Keyboard
Connect
Bluetooth HID Japanese
Keyboard Connect
Bluetooth Disconnect

Honeywell 8680i Specifications

General

Type	Wearable bar code reader
Sensor type	-
Scanner type	1D/2D
Pitch reading angle	-45 - 45 °
Motion tolerance (cm/s)	584
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	Code 39, PDF417, U.P.C.
2D (matrix & stacked) barcodes supported	Data Matrix, PDF417
Bluetooth version	4.1
Standard interfaces	Bluetooth
Connectivity technology	Wireless
Product color	Black
Built-in display	No
International Protection (IP) code	IP54
Charging time	4 h
Battery voltage	3.6 V
Power source type	Battery
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	81 mm
Width	56 mm
Weight	- g
