ID50 Series Panel - Installation, Commissioning & Configuration Manual
Introduction
6997-263-000-11, Issue 11
January 2010
1.10 Glossary of Icons
Throughout this manual, and the other related ID50
Series Panel manuals, a number of icons are used either
as part of the illustrated process descriptions, or in the
main text to help clarify, or simplify, particular
configuration procedures.
The following icons are used to advise or indicate:
a. DO follow the recommended procedure or method.
b. DO NOT use this procedure or method.
c. Inspection of an item or sub-assembly is required at
this point.
d. Following a defined process meets/ does not meet
the required approval/inspection criteria or standards.
e. Additional items to be considered.
f. This icon placed next to a pushbutton requires you to
press it while configuring the panel. Where two or
more icons are used, a number may be placed on or
near each hand to indicate the order of selection: 1
coming before 2.
g. Activity process step - flow arrow for single action or
iterative actions.
h. Leader arrow - used with activity processes.
i. Internal buzzer operating/not-operating or silenced.
j. Sounder operating/not-operating or silenced.
k. Power connected and switched ON/disconnected and
switched OFF.
l. Manual Call Point (MCP)/Sensor.
