ID50 Series Panel - Installation, Commissioning & Configuration Manual
Introduction
1
997-263-000-11, Issue 11
January 2010
1 Introduction
1.1 Manual Purpose
The purpose of this manual is to provide the user with all
recommended procedures and full technical details for
the successful installation, commissioning and
programming of a NOTIFIER ID50 Series Panel.
The descriptions and procedures also apply to the
NOTIFIER ID60 panel. Differences between the ID50 and
ID60 panels are given in Appendix 2.
Procedures described in this manual include appropriate
warnings and cautions to guide the user towards adopting
safe and methodical work practices during the installation,
commissioning and programming phases.
The ID50 Series panels support OPAL protocol devices.
These devices support both OPAL and CLIP loop polling
protocols so they can be added to an existing CLIP
protocol loop. However, when OPAL protocol is enabled
on a loop a maximum of 10 CLIP device addresses can
be supported as part of the total of 99 sensors and 99
modules.
Important Note
This manual must be read, and its content clearly
understood, before proceeding with any work relating to
the ID50 Series Panel. Damage to the control panel may
result from NOT following the recommended procedures
described in this manual.
This manual provides all necessary instructions for the
ID50 Series Panel and applies only to fire panels fitted
with compatible software.
CAUTION: In particular, care must be taken when
powering up/down any repeaters.
If there are any areas of doubt, consult your supplier
before continuing with the system installation,
commissioning and programming.
1.2 System Design and Planning
It is assumed that the system, of which the ID50 Series
Panel equipment is a part, has been designed by a
competent fire alarm system designer in accordance with
the requirements of EN54 Part 14 and any other local
codes of practice that are applicable.
The design drawings should clearly show the positions
of all the ID50 Series Panel control equipment and field
devices.
