Touchpoint Plus User Guide
MAN0984_Iss 4_01/19 Touchpoint Plus
Pt. No. 3011M5001 101 Technical Handbook
7.17 Monitoring TPPL via the Optional Web Interface
The Web Interface is an optional external PC interface tool that provides remote web clients with TPPL data in real
time.
The following browsers are currently supported:
• Chrome
• Internet Explorer 10, Internet Explorer 11
• Internet Explorer 8, Internet Explorer 9 (Trend / Plot is not available)
• Safari
• Other browsers may work but their performance may vary.
Note: Contact Honeywell Support (refer to back page of this manual) if a browser security update causes
performance issues.
7.17.1 Web Interface Configuration
The Web Interface supports two concurrent web clients. Further users may connect, but performance may be
degraded.
The TPPL Default IP address is 192.168.0.100. To change the IP address refer to Ch.6.11 Network Settings for WEB
and MODBUS TCP.
The Web Interface shows the current TPPL status as follows:
• Channel List View shows up to six inputs and events with automatic scrolling
• Channel Summary View shows total counts for alarm 1, alarm 2, alarm 3, fault, warning and inhibits
• Channel Output View shows up to eight outputs and events
Key to examples below:
• Channel marking in red one or more input channels are in Alarm
• Channel marking in yellow one or more channels are in Fault
• Channel marking in orange one or more channels are in Inhibit
• Channel marking in blue one or more channels are in Warning
