Honeywell Touchpoint Plus Technical Handbook

MAN0984_Iss 4_01/19 Touchpoint Plus
Pt. No. 3011M5001 42 Technical Handbook
Grounding for Screened and Armoured Cable with Plastic Junction Box and Sensor
Grounding for Screened Cable with Plastic Junction Box and Sensor
5.2.11 mV Input Module Connections
Module Label
Terminal
Identifier
Field device
mV In 1
1
S
Sensitive (+)
2
01
Signal
3
NS
Sensitive ( )
mV In 2
4
S
Sensitive (+)
5
01
Signal
6
NS
Sensitive ( )
mV In 3
7
S
Sensitive (+)
8
01
Signal
9
NS
Sensitive ( )
mV In 4
10
S
Sensitive (+)
11
01
Signal
12
NS
Sensitive ( )
mV In 5
13
S
Sensitive (+)
14
01
Signal
15
NS
Sensitive ( )
mV In 6
16
S
Sensitive (+)
17
01
Signal
18
NS
Sensitive ( )
