Commissioning
MAN0984_Iss 4_01/19 Touchpoint Plus
Pt. No. 3011M5001 50 Technical Handbook
Chapter 6.
This chapter explains several tasks that may be required during commissioning.
First time switch-on and Commissioning should only be carried out by a Honeywell Analytics engineer or by a
qualified person who has been trained in accordance with this manual.
During first time switch-on, it will be necessary to confirm or set the Date, Time and Language, to set new passwords
and delete the default password, and to program password protected items shown in the menu structures below.
If the system was ordered from Honeywell Analytics, carry out Ch.6.13 Commission Input / Output Modules and
Ch.7.6 Channel Configuration for the input channels before proceeding with Ch.6.14 Channel Configuration for the
Relay Output channels and the mA Output channel.
6.1 Menu Structure
The tables below show the full Menu tree but not all items are available to all users. In particular Service Mode and
Update System can only be accessed by logging on as the Administrator.
6.1.1 The Information Menu
The Information Menu contains non-editable summaries of the current system configuration and it can be read by all.
CAUTION
When commissioning is complete, user shall conduct the initial check as required by each sensor's
user manual (e.g. bump test, accuracy test and etc.) as well as check of Touchpoint Plus mA output
and relay operation as required by this manual. Each sensor connected to Touchpoint Plus shall be
regularly gas calibrated per the recommended interval by sensor's user manual. In addition,
Touchpoint Plus mA output and relay operation shall be regularly checked as required by this
manual.
