Technical Specifications
MAN0984_Iss 4_01/19 Touchpoint Plus
Pt. No. 3011M5001 125 Technical Handbook
11.3.4 mA Output Module
Description
4-channel Analogue Output Module for 2 wire 4 20 mA
signals
Module Power Consumption (Max.)
4.2 W (with 700 mA loop resistance @ 20 mA output)
Sensor Configuration
2-wire current source, Isolated current loop output
Signal Measurement Range
0 20 mA (4 20 mA = 0 100% scale)
Loop Resistance
33 700 Ω
11.3.5 Relay Output Module
Description
12-channel Relay Output Module incorporating 12 single
pole change over (SPDT) relays
Power Consumption Maximum
2.5 W (with all relays energised)
Relay Contacts
1.7 A @ 250 VAC / 1.7 A @ 30 VDC
Relay Operation
Individually configurable for normally energised / de-
energised operation
11.3.6 Expansion Module
Cable between Basic and Expansion
units
<10 m, 18 20 AWG, shielded twisted pair
11.4 Power Supplies
11.4.1 External Supplies
SMPS Power Supply
156 W
AC Input Voltage Range (~)
AC 110/220 V ±10 % of nominal (manual switching)
DC Input Voltage Range ( )
DC 18 32 V SELV Supply
Input Frequency Range (~)
AC 50 60 Hz ± 6 %
Output Voltage ( )
DC 24 V
Dimension
199 x 98 x 38mm (L x W x H)
