Touchpoint Plus User Guide
MAN0984_Iss 4_01/19 Touchpoint Plus
Pt. No. 3011M5001 82 Technical Handbook
7.2 Touchscreen
The Touchscreen is touch only and does not support swipe or pinch gestures.
The Touchscreen has four access levels: View mode is available to all users while Configuration, Maintenance and
System Test functions are password protected. (See Ch.7.4 Menu Items and Access Levels for further information.)
There are only three passworded accounts: Administrator, Service and Operator, and their passwords must be
carefully guarded.
Lost passwords can only be replaced by someone higher which, in the case of the Administrator, will be a Honeywell
representative.
Password holders should be assigned to one access level only.
7.3 Switching On and Off
Before switching power on, ensure that the system has been commissioned or that a qualified person has checked
that the wiring is safe and conforms to local regulations. Also check that the battery isolator switches are in the
correct position and that an SD Card is fitted. Check that the optional expansion unit battery switches are in the
correct position.
Switch on power at the Isolator switch and wait for the system to initialise. (The system start up sequence may last for
up to 5 minutes depending on the number of channels in use.)
TPPL will first display the auto-scrolling Input screen, indicating the current status of the system. The Channel List
View is shown below. The screenshot shows installed sensors but it may be blank depending on your system status:
You can alter the screen views or gain further information by touching the icons shown below:
Table 13. Home Screen Menu Icons
