Repairs, Replacements and Upgrades
MAN0984_Iss 4_01/19 Touchpoint Plus
Pt. No. 3011M5001 117 Technical Handbook
16) Transfer the backup data to a dated folder on a PC or digital device for safekeeping. The Configuration backup
file is stored on the SD Card in \\CFG\ [your file name] and you can reuse the SD card once the data
has been transferred.
Note: You cannot restore configuration files if the I/O module configuration has changed since the last backup.
9.5.2 To Restore the Configuration From a Backup File
Note: The Touchpoint Plus system must be turned off to change the SD card so alternative safety arrangements
should be put in place prior to starting this procedure.
1) Login as Administrator.
2) Touch Menu>Maintenance>Power-off>Yes.
3) Switch off and isolate the TPPL power supplies.
4) Open the TPPL enclosure door.
5) Temporarily replace the TPPL SD Card with one holding the backup file \\CFG\[your file name]
6) Close the enclosure door.
7) Switch power back on and wait for the system to stabilise.
8) Login as Administrator.
9) Touch Menu>Configuration>Config Manager>Import , then choose your backup file and touch
Select>Yes.
10) Once the action is confirmed, the configuration restoration process starts and a progress message is displayed.
The process may take several minutes depending on the system size.
To Next Page
