6.1.3 The Maintenance Menu
The Maintenance Menu is where commissioning and maintenance tasks can be accessed. Most of this menu is
available to Service Engineers, but Service Mode and system updates can only be authorised by the Administrator.
Menu Level 1
Menu Level 2
Menu Level 3
Menu Level 4
Maintenance
Reset alarms / Faults
Yes / No
N/A
Reset All Peaks
Yes / No
N/A
Gas Calibration
Wizard
N/A
Adjust mV Baseline
Wizard
N/A
SD Card
Format / Eject
N/A
Power Off
Yes / No
N/A
Service Mode
(Administrator)
Electronic Adjustment
Requires multi-meter and technical skills
Reset to Default
Yes / No
Update System
(Administrator)
Software
Update File required
Language
Update File required
Sensor Catalog
Update File required
Module Data
Update File required
Maintenance Menu
6.1.4 System Test Menu
This menu allows a Service Engineer to test / emulate various system functions. Access is restricted to Service or
Admin users
Menu Level 1
Menu Level 2
Menu Level 3
Menu Level 4
System Test
Force Relay
Module Select
System / Channel (On/Off)
Force 4 20mA
Channel to Force (All /
Single)
New Output Value ( in mA)
Relay C&E Matrix
Select Relay Channel
Input Select Auto-fill (A1, A2, A3, FLT, INHIB,
WARN)
Input Channel (Selective Inputs - Scrollable)
Vote Count Summary
Channels Selected Summary
Dedicated Alarm
Contacts
Visible Alarm
On / Off
Audible Alarm 1
On / Off
Audible Alarm 2
On / Off
Audible Alarm 3
On / Off
LCD Test
Yes / No
LED & Buzzer
Yes / No
System Test Menu
