S-Quad Sensors with Visual alarm device (VAD) - introduced post April 2014
The following S-Quad with VAD sensors when operating in the STATES shown in table below are LPCB approved to the respective standard.
Part number Description Standard
S4-711-VAD-HPR S4 Dual Optical & Heat Sensors / Red VAD EN54-5 : 2000, A1 : 2002 (heat)
EN54-7 : 2000, A1 : 2002, A2 : 2006 (optical)
EN54-3 : 2001, A1 : 2002, A2 : 2006 (sounder)
EN54-23 : 2010 (visual alarm device VAD)
EN54-17:2005 (short circuit isolator)
EN54-18:2005 (input output devices)
S4-720-V-VAD-HPR S4 Heat sensor / Voice Sensor Sounder / Red VAD
S4-711-V-VAD-HPR S4 Dual Optical & Heat Sensors / Voice Sounder / Red VAD
S4-911-V-VAD-HPR S4 Dual Optical & Heat & CO Sensors / Voice Sounder / Red VAD
S4-711-VAD-LPW S4 Dual Optical & Heat Sensors / White VAD
S4-711-VAD-HPW S4 Dual Optical & Heat Sensors / White VAD (HP)
S4-711-V-VAD-LPW S4 Dual Optical & Heat Sensors / Voice Sounder / White VAD (Std)
S4-711-V-VAD-HPW S4 Dual Optical & Heat Sensors / Voice Sounder / White VAD (HP)
S4-720-V-VAD-HPW S4 Heat / Voice Sounder / White VAD (HP)
S4-911-V-VAD-HPW S4 Dual Optical & Heat & CO Sensors / Voice Sounder / White VAD HP
Non VAD devices
S4-720 Heat sensor EN54 : Part 5 :2002* - (heat)
S4-715 Optical sensor EN54 : Part 7 : 2000* - (optical smoke)
S4-710 Optical Heat sensors EN54 : Part 7 : 2000* - (optical smoke)
EN54 : Part 5 : 2000* - (heat)
CEA 4021 : 2003-07 Class P heat multisensor detector
S4-711 Dual Optical & Heat Sensors
S4-711-V S4 Dual Optical & Heat Sensors / Voice Sounder EN54-5 : 2000, A1 : 2002 (heat)
EN54-7 : 2000, A1 : 2002, A2 : 2006 (optical)
EN54-3 : 2001, A1 : 2002, A2 : 2006 (sounder)
EN54-17:2005 (short circuit isolator)
EN54-18:2005 (input output devices)
S4-770-S S4 Optical & Heat Sensors / Sounder
S4-771-S S4 Dual Optical & Heat Sensors / Sounder
S4-780-S S4 Heat Sensor Sounder
S4-901 S4 Dual Optical & Heat & CO Sensors
* - these standards are met when the sensor is operating LPCB approved STATES, see STATES table below. Sounder tone description - see next page
"
If a S-Quad sensor is configured to operate a non LPCB STATE, then this will contravene the LPCB approval. The required STATE is configured during commissioning and
can be also configured using controls at the main panel.
4188-856_issue 7_07/15_Generic Vigilon (Compact + VA) Comms. 13
Vigilon 4/6 loops & Compact (VA) panels & network nodes
Product Approval and Standards
