S-Quad Sensor with Strobe - STATES (legacy devices)

The STATE in which the S-Quad sensors operate can be changed from the default factory set STATE to another STATE during commissioning. The environment in which the S-Quad device is installed

will determine what STATE is applicable. # - Factory Default STATE ~ EN54 : Part 7 :2000 * EN54 : Part 5 :2002 ¯ - used in current range

The release of control panel software (MCC/MCB equal to or greater than V4.41):

If a non defined STATE is selected during commissioning then the control panel will revert to STATE 0.

The previous release of control panel software (MCC/MCB less than V4.41):

If a non defined STATE is selected during commissioning then the control panel will revert to STATE 15, which means the device is functionally switched OFF.

Device

LPCB approved STATE

Meets ~ EN54 : Part 7 :2000

* EN54 : Part 5 :2002

Dual Optical & Heat sensor variant -

S4-711¯

(With Strobe) S4-711-ST

(With Speech) S4-711-VO

(With Strobe & Speech) S4-711-ST-VO

(With Sounder) S4-771

State 0 # Medium optical smoke ~ / Class A1 heat *

State 5 Medium optical smoke ~ / Class B heat *

State 8 Delayed medium optical smoke ~ / Class A1 heat*

Dual Optical, Heat & CO sensor variant -

S4-911

(With Speech & Strobe) S4-911-ST-VO

State 0 # Medium optical smoke ~ / Class A1 heat *

State 9 Class A1 heat *

Optical & Heat sensor variant -

S4-710¯

(With Sounder) S4-770

State 0 # Medium optical smoke / Class A1 heat*

Heat sensor variant -

S4-720¯

(With Speech & Strobe) S4-720-ST-VO

(With Sounder) S4-780

State 0 # Class A1 heat *

State 5 Class B heat *

Optical senor - S4-715¯

State 0 Medium optical smoke

All S-Quad range of sensor sounder devices meet CEA 4021, where applicable, and meet EN54-17:2005 Short circuit isolation plus EN54-18:2005 Input/Output devices for use on the transmission path

of fire detection and alarm systems.

Commissioning instructions

74 4188-856_issue 7_07/15_Generic Vigilon (Compact + VA) Comms.
