S-Quad Dual Optical, Heat & CO sensor STATES
State Definition / Class Application in / Suitable for:
Sensitivity
a-high- to-h-none
State 1 High sensitivity optical, Class A1 heat,
high sensitivity gas
Clean area or environment where early detection is required with false alarm reduction
a
State 4 Medium sensitivity optical with spike
protection, Class A1 heat, medium
sensitivity gas
General area as State 0 with less immunity to steam and dust for ease of testing using artificial
smoke in normal operating mode, when test / commissioning mode is not active
b
State 0#
Medium sensitivity optical,
Class A1 heat, medium sensitivity gas
General area where false alarm reduction is required for comprehensive fire detection
c
State 2 Medium sensitivity optical,
Class A1 heat, low sensitivity gas
Applications with moderate dust, smoke (tobacco) or steam
d
State 9 Medium sensitivity gas,
Class A1 heat
Area where high levels of smoke, dust or steam is often present
e
State 11 Medium sensitivity optical,
Class B heat
Area with high ambient temperature, plus low levels of dust, smoke or steam present
f
State 12 Class A1 heat only Area where smoke, dust, steam or gas occurs at times
g
State 15 No detection
h
S-Quad Optical sensor STATES
# - factory default STATE
State Definition / Class Application in / Suitable for:
Sensitivity
a-high- to-f-none
State 3 High sensitivity optical Clean area or environment, where early detection is required a
State 4 Medium sensitivity with no spike
protection
General area as State 0 with less immunity to steam and dust to facilitate wittiness test b
State 0#
Medium sensitivity optical General area c
State 8 Delayed medium sensitivity optical General area with transient steam, dust or smoke present d
State 2 Low sensitivity optical Area with moderate dust, smoke or steam present e
State 15 No detection f
Commissioning instructions
76 4188-856_issue 7_07/15_Generic Vigilon (Compact + VA) Comms.
S-Quad Sensor with Strobe - STATES (legacy devices)
