Device checks
"
Ensure all dust covers have been removed from the sensor heads and the
system is allowed to operate for at least 24 hours to obtain accurate time average and
condition code readings.
Checking the time averages
Press the Menu On/Off button and then [Info], momentarily press <etc> to select [Time Avg] and
type in the required channel number from the range 1-6 whose time average is required, select
[Device] and type in the device number, select [Loop] and type in the loop number of the device
->[Enter]. The display shows time averages for the device.
Foreground (fast) time average readings
Tnew T1 T2 T3 T4 T5
On
demand
80mS 320mS 1.28S 5.12S 20.48S
Normally reads 252, unless there is a threshold.
Background (slow) time average readings
Tnew T6 T7 T8 T9 T10 T11
On
demand
1.36min 5.46min 21.84min 1.45hr 5.82hr 23.3hr
Product Analogue Channels Time average
Tnew
S4 Heat Sensor 2 - heat 66
S4 Heat Sensor Sounder 2 - heat 66
S4 Dual Optical Heat Sensor 1 - optical (forward)
2 - heat
4 - optical (backward)
25
66
40
S4 Dual OH/Red VAD 1 - Optical (forward)
2 - Heat
4 - Optical (backward)
25
66
40
S4 Heat/Voice Sen Sndr/Red VAD 2 - Heat 66
S4 Dual OH/Voice Sen Sndr/Red VAD 1 - Optical (forward)
2 - Heat
4 - Optical (backward)
25
66
40
S4 Dual OH/CO/Voice Sen Sndr/Red
VAD
1 - Optical (forward)
2 - Heat
3-CO
4 - Optical (backward)
25
66
25
40
S4 Dual OH/White VAD 1 - Optical (forward)
2 - Heat
4 - Optical (backward)
25
66
40
S4 Dual OH/White VAD (HP) 1 - Optical (forward)
2 - Heat
4 - Optical (backward)
25
66
40
S4 Dual OH/Voice Sndr/White VAD (Std) 1 - Optical (forward)
2 - Heat
4 - Optical (backward)
25
66
40
S4 Dual OH/Voice Sen Sndr/White VAD
(HP)
1 - Optical (forward)
2 - Heat
4 - Optical (backward)
25
66
40
S4 Heat/Voice Sndr/White VAD (HP) 2 - Heat 66
S4 Dual OH/CO/Voice Sen Sndr/White
VAD HP
1 - Optical (forward)
2 - Heat
3-CO
4 - Optical (backward)
25
66
25
40
Commissioning instructions
68 4188-856_issue 7_07/15_Generic Vigilon (Compact + VA) Comms.
Device checks
Average Channel 1 Device 1 Loop 1
19 252 252 252 252 252 19 19 19 19 18 18
Time average readings of Channel 1 device 1 loop 1
23:15
Tnew (On demand)
Background (slow) Time
average readings T6 of T11
Channel 1 Device 1 loop 1
Foreground (fast) Time
average readings T1 to T5 of
Channel 1 Device 1 loop 1
e Aver channel 1 Device 1 Loop 1
[Repeat] [Previous] [Next] [Cancel]
